| 規(guī)格名稱 | LDC625-F700-T18 |
|---|---|
| 額定扭矩(Rated Torque) | 2050N.m |
| 最大扭矩(Max Torque) | 4050N.m |
| 額定轉(zhuǎn)速(Rated Speed ) | 30rpm |
| 最高轉(zhuǎn)速(Max Speed) | 60rpm |
| 定位精度(Accuracy Range) | 20arcsec |
| 重復(fù)精度(Repeat Accuracy) | 5arcsec |
| 額定電流(Rated Current) | 18A |
| 最大電流(Max Current) | 36A |
| 編碼器類型(Encoder Type) | Biss-d/ Endat2.112.2 |
| 電源(Power Supply) | AC:380V |
